Description

How it behaves

  •

What do Pulse Transformers aim to solve

  •

  • Used in isolated buck/forward converter
  • Generally costlier than flyback, but cheaper than push-pull
  • Power ranges:
          o   Conventional forward converter → <500W
          o   Interleaved forward converter    → up to 1kW

Voltage (RMS/peak) 400V / 480V
Current (RMS/peak) 10A / 15A
Maximum Power < 500W
Inductance 100µH - 1mH
Leakage Inductance ~ 10µH
Switching Frequency 40kHz - 120kHz

  • DC-DC forward converters
  • AC-DC converters
  • Telecommunication equipment
  • Medical devices
  • Solar/photovoltaic
  • Battery storage & chargers

Frequently asked questions
