Description

How it behaves

  •

What do Hybrid Planar Transformers aim to solve

  •

  • AC circuit filter → attenuate high frequency noise, in series with current pathway, from harmonics in AC current → “AC choke” or “ AC power choke”
  • Maintain inductance over specified frequency range

+ Low parasitic capacitance → High self-resonant frequency > 5MHz *

* High inductance or inductors with many turns → lower self-resonant frequency

Voltage (RMS/peak) 450V / 500V
Current (RMS/peak) 150A / 250A
Maximum Power * 30kW
Inductance ~ 100µH
Switching Frequency 30kHz – 800kHz

* Switching above 300kHz limits max. power, whereas lower frequency will extend the given power range

  • Passive filters
  • Resonant and phase-shift converters/inverter topologies
