Description

How it behaves

  •

What do Moulded Connectors aim to solve

  •

  • AC circuit filter → attenuate high frequency noise, in series with current pathway, from harmonics in AC current → “AC choke” or “ AC power choke”
  • Maintain inductance over specified frequency range

+ Low parasitic capacitance → High self-resonant frequency > 5MHz *

* High inductance or inductors with many turns → lower self-resonant frequency

Voltage (RMS/peak) 24V / 26V
Current (RMS/peak) 0.8A / 1A
DC Resistance < 3mΩ
Inductance ~ 3mH
Q Factor * < 10
Frequency ** 50Hz - 400kHz

* Depends on working frequency range (High Q at operating frequency, Low Q at noise frequency)
** High frequencies, especially above 300kHz, will limit power handling

  • Passive filters
  • Resonant and phase-shift converters/inverter topologies
